Delivery Channels and Content

This guide will cover what a Delivery Channel is and how to use the Content APIs.

Suggest Edits

Pre-requisites

  1. First Orion Branded Communications agreement
  2. Access to First Orion Customer Portal
  3. Vetted and Approved Business
  4. Understanding of First Orion's Authentication Endpoint
  5. A Program to assign Delivery Channels to
  6. Tool/Service to invoke API Endpoints (cURL examples shown here)

Understanding

Delivery Channels

Delivery Channels in First Orion's platform dictate what kind of Branding and or Blocking behavior a Program and the associated Phone Numbers should have. This is how we assign Inform Text and Logo (Image) Branding and Sentry Blocking to a Phone Number.

Content APIs

What is Content? That is any Branding added to First Orion's platform, so Display Names and Images.

Why? This allows for the reuse of Content (Branding) between Programs so no additional vetting is needed when the same Branding is going to be used.

How are they related?

We assign Content to a Delivery Channel, specifically the CallerName and CallerImage channels, to get Branding.

Prior to making a Program, use the Content APIs to create Branding. Then Create or Update a Program's Delivery Channels like normal using the IDs from the created Content (See Examples Below).

Is there an easier way?

Yes, use the First Orion Portal. See how to setup a Branding Program using the Portal in this

Quick Start Guide

Delivery Channels

We use three Delivery Channel types:

  1. CallerName: This is used to assign the Inform Text Display to a Program.
  2. CallerImage: This is used to assign a Inform with Logo (Image) Display to a Program.
  3. Blocking: This is used to assign Sentry functionality to a Program.

Here is a screenshot from the First Orion Portal. Notice the Program Types column. The one marked, "SENTRY", has Blocking assigned. The one marked, "INFORM", is a standard Inform Program and only has CallerName assigned to it. The last one marked, "INFORM PAIRED", has both the CallerName and CallerImage assigned along with the Call Authentication Functionality (Paired).

Here are examples of what the getting those Delivery Channels looks like using the Get Delivery Channels Endpoint.

{
    "body": {
        "callerName": {
            "asset": {
                "longName": "Big Box - Outreach",
                "shortName": "BigBox Outreach",
                "channelApprovals": [
                    "tmobile"
                ],
                "displayNameContentId": "3367cd9c-c552-4161-a8d2-5ba18e0e4aa7"
            }
        },
    "error": null
}

{
    "body": {
        "callerName": {
            "asset": {
                "longName": "Big Box - Outreach",
                "shortName": "BigBox Outreach",
                "channelApprovals": [
                    "tmobile"
                ],
                "displayNameContentId": "3367cd9c-c552-4161-a8d2-5ba18e0e4aa7"
            }
        },
        "callerImage": {
            "asset": {
                "displayNameContentId": "3367cd9c-c552-4161-a8d2-5ba18e0e4aa7",
                "subjectContentId": "a703d711-0b2c-41a3-b5ca-3366f82dde52",
                "imageContentId": "e88608c5-17fe-4db3-acf3-e1275da2702c",
                "informPremiumEnabled": true
            }
        }
    },
    "error": null
}

{
    "body": {
        "blocking": {
            "asset": {
                "active": true
            }
        }
    },
    "error": null
}

{
    "body": {
        "callerName": {
            "asset": {
                "longName": "Big Box - Outreach",
                "shortName": "BigBox Outreach",
                "channelApprovals": [
                    "tmobile"
                ],
                "displayNameContentId": "3367cd9c-c552-4161-a8d2-5ba18e0e4aa7"
            }
        },
        "blocking": {
            "asset": {
                "active": true
            }
        }
    },
    "error": null
}

Content APIs

This section will cover how to use the Content APIs.

NOTE: Content can NOT be deleted. This should not affect any functionality, just something to keep in mind.

Step 1a - Display Name Content

Display Name Content is assigned to the CallerName Delivery Channel to get the Inform Text Display.

Here is an example of creating Display Name Content. Notice the pending status in the response. Content will need to be approved before being assigned to a Delivery Channel. Save the Content ID for later.

  • To check if the Display Name is approved, use this List Content Display Names request. Check the third and fourth tabs for examples.
curl --request POST \
     --url 'https://api.firstorion.com/exchange/v1/businesses/businessId/content/displayNames' \
     --header 'Authorization: Token String' \
     --header 'accept: application/json'
     --data'
{
    "longName": "Good Invest - Fraud Alert",
    "shortName": "Fraud Alert",
    "note": "Display Name for Fraud Detection teams outgoing calls"
}
'

{
    "body": {
        "contentId": "a813e38c-8730-4ce4-80b1-0bead1186e4d",
        "resellerId": "186e4d8c-8730-3dee-80b1-4d59d11880b1",
        "businessId": "719d140e-fd6c-4d59-9241-3dee71b38320",
        "type": "DISPLAY_NAME",
        "status": "PENDING",
        "note": "Display Name for Fraud Detection team's outgoing calls",
        "longName": "Good Invest - Fraud Alert",
        "shortName": "Fraud Alert"
    },
    "error": null
}

curl --request GET \
     --url 'https://api.firstorion.com/exchange/v1/businesses/businessId/content/displayNames' \
     --header 'Authorization: Token String' \
     --header 'accept: application/json'

{
  "body": [
    {
      "contentId": "a813e38c-8730-4ce4-80b1-0bead1186e4d",
      "resellerId": "186e4d8c-8730-3dee-80b1-4d59d11880b1",
      "businessId": "719d140e-fd6c-4d59-9241-3dee71b38320",
      "type": "DISPLAY_NAME",
      "status": "APPROVED",
      "lastUpdated": "1702249909",
      "lastUpdatedBy": "VETTING_ORCHESTRATOR",
      "note": "Display Name for Fraud Detection team's outgoing calls",
      "longName": "Good Invest - Fraud Alert",
      "shortName": "Fraud Alert"
    }
  ],
  "error": null
}

Step 1b - Image Content

Image Content is assigned to the CallerImage Delivery Channel to get the Inform with Logo Display.

Here is an example of creating Image Content. Notice the pending status in the response. Content will need to be approved before being assigned to a Delivery Channel. Save the Content ID for later.

curl --request POST \
     --url 'https://api.firstorion.com/exchange/v1/businesses/businessId/content/images' \
     --header 'Authorization: Token String' \
     --header 'Content-Type: application/json' \
     --data '
{
  "name": "Official Company Logo",
  "note": "Example Note",
  "content": "<base64 encoded string>"
}
'

{
    "contentId": "a813e38c-8730-4ce4-80b1-0bead1186e4d",
    "resellerId": "186e4d8c-8730-3dee-80b1-4d59d11880b1",
    "businessId": "719d140e-fd6c-4d59-9241-3dee71b38320",
    "type": "IMAGE",
    "status": "PENDING",
    "lastUpdated": "1710867472",
    "lastUpdatedBy": "VETTING_ORCHESTRATOR",
    "note": "Example Note",
    "name": "Official Company Logo",
    "originalImageUrl": "https://imageURL.com/a813e38c-8730-4ce4-80b1-0bead1186e4d.svg",
    "renderedImages": [
        {
            "format": "png",
            "url": "https://imageURL.com/a813e38c-8730-4ce4-80b1-0bead1186e4d.png",
            "width": 256,
            "height": 256,
            "sha256": "sha256-0eed92ecdf9de969c1dcf9a75c4dc33dba20fd7a79d",
            "jCard": {
                "content": "deef8a00adafeb7e84f9dc14cc5eecd6ddcab0e239a46c9dc1cdaa6b7c62bd64c4f80470a20bdc4c3a308ce9a5557cb71b723e8d6a4478a5447cf81a31a814b1bebac48e7bc4bb6c7eff9de8a9e1bdc97e5fa4af78adbbd9ef11aeb",
                "url": "https://dj7zr6u6ivguf.cloudfront.net/0ee41f9c-1845-4be8-929d-bb60cf85a0a8.png.json",
                "sha256": "sha256-/ad1ce2b4bd5af0fbd125466a803f010bb018534ebe"
            }
        },
        {
            "format": "jpg",
            "url": "https://imageURL.com/a813e38c-8730-4ce4-80b1-0bead1186e4d.jpg",
            "width": 256,
            "height": 256,
            "sha256": "sha256-1aa2981cffd9c44beced90c81d5537b71e6dcacb105",
            "jCard": {
                "content": "deef8a00adafeb7e84f9dc14cc5eecd6ddcab0e239a46c9dc1cdaa6b7c62bd64c4f80470a20bdc4c3a308ce9a5557cb71b723e8d6a4478a5447cf81a31a814b1bebac48e7bc4bb6c7eff9de8a9e1bdc97e5fa4af78adbbd9ef11aeb",
                "url": "https://dj7zr6u6ivguf.cloudfront.net/0ee41f9c-1845-4be8-929d-bb60cf85a0a8.jpg.json",
                "sha256": "sha256-c76ed98dc8edb9142f9effab92a4ac5d863f84b227"
            }
        },
        {
            "format": "bmp",
            "url": "https://imageURL.com/a813e38c-8730-4ce4-80b1-0bead1186e4d.bmp",
            "width": 256,
            "height": 256,
            "sha256": "sha256-d78a4dfc72beef5bcff9bdfa6d27e1eaadeafcdbb11",
            "jCard": {
                "content": "deef8a00adafeb7e84f9dc14cc5eecd6ddcab0e239a46c9dc1cdaa6b7c62bd64c4f80470a20bdc4c3a308ce9a5557cb71b723e8d6a4478a5447cf81a31a814b1bebac48e7bc4bb6c7eff9de8a9e1bdc97e5fa4af78adbbd9ef11aeb",
                "url": "https://dj7zr6u6ivguf.cloudfront.net/0ee41f9c-1845-4be8-929d-bb60cf85a0a8.bmp.json",
                "sha256": "sha256-e0e8c28a4bc5e4f2b23ba1cbab42e5fd2cb27bfedc"
            }
        }
    ]
}

curl --request GET \
     --url 'https://api.firstorion.com/exchange/v1/businesses/businessId/content/images' \
     --header 'Authorization: Token String' \
     --header 'Content-Type: application/json' \

{
    "contentId": "a813e38c-8730-4ce4-80b1-0bead1186e4d",
    "resellerId": "186e4d8c-8730-3dee-80b1-4d59d11880b1",
    "businessId": "719d140e-fd6c-4d59-9241-3dee71b38320",
    "type": "IMAGE",
    "status": "APPROVED",
    "lastUpdated": "1710867472",
    "lastUpdatedBy": "VETTING_ORCHESTRATOR",
    "note": "Example Note",
    "name": "Official Company Logo",
    "originalImageUrl": "https://imageURL.com/a813e38c-8730-4ce4-80b1-0bead1186e4d.svg",
    "renderedImages": [
        {
            "format": "png",
            "url": "https://imageURL.com/a813e38c-8730-4ce4-80b1-0bead1186e4d.png",
            "width": 256,
            "height": 256,
            "sha256": "sha256-0eed92ecdf9de969c1dcf9a75c4dc33dba20fd7a79d",
            "jCard": {
                "content": "deef8a00adafeb7e84f9dc14cc5eecd6ddcab0e239a46c9dc1cdaa6b7c62bd64c4f80470a20bdc4c3a308ce9a5557cb71b723e8d6a4478a5447cf81a31a814b1bebac48e7bc4bb6c7eff9de8a9e1bdc97e5fa4af78adbbd9ef11aeb",
                "url": "https://dj7zr6u6ivguf.cloudfront.net/0ee41f9c-1845-4be8-929d-bb60cf85a0a8.png.json",
                "sha256": "sha256-/ad1ce2b4bd5af0fbd125466a803f010bb018534ebe"
            }
        },
        {
            "format": "jpg",
            "url": "https://imageURL.com/a813e38c-8730-4ce4-80b1-0bead1186e4d.jpg",
            "width": 256,
            "height": 256,
            "sha256": "sha256-1aa2981cffd9c44beced90c81d5537b71e6dcacb105",
            "jCard": {
                "content": "deef8a00adafeb7e84f9dc14cc5eecd6ddcab0e239a46c9dc1cdaa6b7c62bd64c4f80470a20bdc4c3a308ce9a5557cb71b723e8d6a4478a5447cf81a31a814b1bebac48e7bc4bb6c7eff9de8a9e1bdc97e5fa4af78adbbd9ef11aeb",
                "url": "https://dj7zr6u6ivguf.cloudfront.net/0ee41f9c-1845-4be8-929d-bb60cf85a0a8.jpg.json",
                "sha256": "sha256-c76ed98dc8edb9142f9effab92a4ac5d863f84b227"
            }
        },
        {
            "format": "bmp",
            "url": "https://imageURL.com/a813e38c-8730-4ce4-80b1-0bead1186e4d.bmp",
            "width": 256,
            "height": 256,
            "sha256": "sha256-d78a4dfc72beef5bcff9bdfa6d27e1eaadeafcdbb11",
            "jCard": {
                "content": "deef8a00adafeb7e84f9dc14cc5eecd6ddcab0e239a46c9dc1cdaa6b7c62bd64c4f80470a20bdc4c3a308ce9a5557cb71b723e8d6a4478a5447cf81a31a814b1bebac48e7bc4bb6c7eff9de8a9e1bdc97e5fa4af78adbbd9ef11aeb",
                "url": "https://dj7zr6u6ivguf.cloudfront.net/0ee41f9c-1845-4be8-929d-bb60cf85a0a8.bmp.json",
                "sha256": "sha256-e0e8c28a4bc5e4f2b23ba1cbab42e5fd2cb27bfedc"
            }
        }
    ]
}

Step 1c - Subject Content (Optional)

Subject Content is assigned to the CallerImage Delivery Channel and is used for Inform with Logo. The result is that the final display will have an extra line of text content. Note: Not every device that can receive logo can receive the subject content.

Here is an example of creating Subject Content. Notice the pending status in the response. Content will need to be approved before being assigned to a Delivery Channel. Save the Content ID for later.

To check if the Subject Content is approved, use this List Content Display Names request. Check the third and fourth tabs for examples.

curl --request POST \
     --url 'https://api.firstorion.com/exchange/v1/businesses/719d140e-fd6c-4d59-9241-3dee71b38320/content/subjects' \
     --header 'Authorization: Token String' \
     --header 'Content-Type: application/json' \
'
{
  "subject": "Fraud Alert",
  "note": "Subject note example"
}
'

{
  "body": [
    {
      "contentId": "a813e38c-8730-4ce4-80b1-0bead1186e4d",
      "resellerId": "186e4d8c-8730-3dee-80b1-4d59d11880b1",
      "businessId": "719d140e-fd6c-4d59-9241-3dee71b38320",
      "type": "SUBJECT",
      "status": "PENDING",
      "lastUpdated": "1702249909",
      "lastUpdatedBy": "VETTING_ORCHESTRATOR",
      "subject": "Fraud Alert",
      "note": "Subject note example"
    }
  ],
  "error": null
}

curl --request GET \
     --url 'https://api.firstorion.com/exchange/v1/businesses/719d140e-fd6c-4d59-9241-3dee71b38320/content/subjects' \
     --header 'Authorization: Token String' \
     --header 'Content-Type: application/json' \

{
  "body": [
    {
      "contentId": "a813e38c-8730-4ce4-80b1-0bead1186e4d",
      "resellerId": "186e4d8c-8730-3dee-80b1-4d59d11880b1",
      "businessId": "719d140e-fd6c-4d59-9241-3dee71b38320",
      "type": "SUBJECT",
      "status": "APPROVED",
      "lastUpdated": "1702249909",
      "lastUpdatedBy": "VETTING_ORCHESTRATOR",
      "subject": "Fraud Alert",
      "note": "Subject note example"
    }
  ],
  "error": null
}

Step 2 - Create Delivery Channel

This step assumes a Program has been made up to the point of Creating a Delivery Channel.

NOTE: The Content MUST be approved to assign. Check previous steps.

CallerName

Caller Name can be assigned with either the Display Name Content ID (tab 1) or with the literal Display Name that is desired (tab 2). Either way, it will the same endpoint and receive the same response.

curl --request POST \
     --url 'https://api.firstorion.com/exchange/v1/businesses/719d140e-fd6c-4d59-9241-3dee71b38320/business-units/ec0ce06a-3739-45f5-a804-5468e60a843/programs/df567c99-9354-47e5-b30f-88ee7cbfeab4/delivery-channels/callerName' \
     --header 'Authorization: Token String' \
     --header 'content-type: application/json' \
     --data '
{
  "asset": {
    "displayNameContentId": "8adb9766-2ad0-453a-8a99-ed2b281e5b06"
  }
}
'

curl --request POST \
     --url 'https://api.firstorion.com/exchange/v1/businesses/businessId/business-units/businessUnitId/programs/programId/delivery-channels/callerName' \
     --header 'Authorization: Token String' \
     --header 'Content-Type: application/json' \
     --data '
{
  "asset": {
    "longName": "Good Invest - Fraud Alert",
    "shortName": "Fraud Alert",
    "note": "Display Name for Fraud Detection teams outgoing calls"
  }
}
'

{
  "body": {
    "asset": {
      "longName": "Good Invest - Fraud Alert",
      "shortName": "Fraud Alert",
      "note": "Display Name for Fraud Detection teams outgoing calls",
      "channelApprovals": [
        "tmobile"
      ],
      "displayNameContentId": "1dcb433a-af01-409f-b325-0e226c263a1f"
    }
  },
  "error": null
}

CallerImage

Caller Image must use this format and subjectContentId is optional. This Delivery Channel does require the Display Name Content ID, unlike CallerName.

Note: informPremiumEnabled is just and internal name for using Image/Logo.

curl --request POST \
     --url 'https://api.firstorion.com/exchange/v1/businesses/719d140e-fd6c-4d59-9241-3dee71b38320/business-units/ec0ce06a-3739-45f5-a804-5468e60a843/programs/df567c99-9354-47e5-b30f-88ee7cbfeab4/delivery-channels/callerImage' \
     --header 'Authorization: Token String' \
     --header 'Content-Type: application/json' \
     --data '
{
  "asset": {
    "displayNameContentId": "8adb9766-2ad0-453a-8a99-ed2b281e5b06",
    "subjectContentId": "adfeee-4102-562a-k44s-k2ks8gj50f3m",
    "imageContentId": "e6ada17e-419d-408a-91ad-f060260a5db2",
    "informPremiumEnabled": true
  }
}
'

{
  "body": {
    "asset": {
      "displayNameContentId": "8adb9766-2ad0-453a-8a99-ed2b281e5b06",
      "subjectContentId": "adfeee-4102-562a-k44s-k2ks8gj50f3m",
      "imageContentId": "e6ada17e-419d-408a-91ad-f060260a5db2",
      "informPremiumEnabled": true
    }
  },
  "error": null
}

Updating Content

  1. Create new Content and gather their IDs, see previous steps.
  2. Update using those IDs. The responses are not shown here but they are similar to Creating a Delivery Channel.
curl --request PUT \
     --url 'https://api.firstorion.com/exchange/v1/businesses/719d140e-fd6c-4d59-9241-3dee71b38320/business-units/ec0ce06a-3739-45f5-a804-5468e60a843/programs/df567c99-9354-47e5-b30f-88ee7cbfeab4/delivery-channels/callerImage' \
     --header 'Authorization: Token String' \
     --header 'Content-Type: application/json' \
     --data '
{
  "asset": {
    "displayNameContentId": "8adb9766-2ad0-453a-8a99-ed2b281e5b06",
    "subjectContentId": "adfeee-4102-562a-k44s-k2ks8gj50f3m",
    "imageContentId": "e6ada17e-419d-408a-91ad-f060260a5db2",
    "informPremiumEnabled": true
  }
}
'

curl --request PUT \
     --url 'https://api.firstorion.com/exchange/v1/businesses/719d140e-fd6c-4d59-9241-3dee71b38320/business-units/ec0ce06a-3739-45f5-a804-5468e60a843/programs/df567c99-9354-47e5-b30f-88ee7cbfeab4/delivery-channels/callerName' \
     --header 'Authorization: Token String' \
     --header 'Content-Type: application/json' \
     --data '
{
  "asset": {
    "displayNameContentId": "8adb9766-2ad0-453a-8a99-ed2b281e5b06"
  }
}
'

curl --request PUT \
     --url 'https://api.firstorion.com/exchange/v1/businesses/719d140e-fd6c-4d59-9241-3dee71b38320/business-units/ec0ce06a-3739-45f5-a804-5468e60a843/programs/df567c99-9354-47e5-b30f-88ee7cbfeab4/delivery-channels/callerName' \
     --header 'Authorization: Token String' \
     --header 'Content-Type: application/json' \
     --data '
{
  "asset": {
    "longName": "Good Invest - Fraud Alert",
    "shortName": "Fraud Alert",
    "note": "Display Name for Fraud Detection teams outgoing calls"
  }
}
'

Branding

The Programs should now Brand with the assigned Delivery Channels Contents.

Updated 1 day ago

Docs

Resources

First Orion

© 2024 First Orion Corp.
Privacy Policies | Terms of Use
ISO 27001:2013 certified
